Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
70 | 155/70R13 | 75 | T | 41/2J | 157 | 548 | 250 | 387 |
165/70R13 | 79 | T | 5J | 170 | 562 | 250 | 437 | |
80 | 155/80R13 | 79 | T | 4.50B/4 1/2J | 157 | 578 | 240 | 437 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
60 | 185/60R14 | 82 | H | 51/2J | 189 | 578 | 250 | 475 |
65 | 155/65R14 | 75 | T | 4.50B/41/2J | 157 | 558 | 250 | 387 |
65 | 175/65R14 | 82 | T | 5J | 177 | 584 | 250 | 475 |
70 | 165/70R14 | 81 | T | 5J | 170 | 588 | 250 | 462 |
70 | 175/70R14 | 88/XL | T | 5J | 177 | 602 | 290 | 560 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
50 | 195/50R15 | 82 | V | 6J | 201 | 577 | 250 | 475 |
55 | 185/55R15 | 86/XL | H | 6J | 194 | 585 | 290 | 530 |
60 | 185/60R15 | 88/XL | H | 51/2J | 189 | 603 | 290 | 560 |
195/60R15 | 88 | H | 6J | 201 | 615 | 250 | 560 | |
65 | 175/65R15 | 84 | H | 5J | 177 | 609 | 250 | 500 |
185/65R15 | 88 | H | 51/2J | 189 | 621 | 250 | 560 | |
195/65R15 | 91 | H | 6J | 201 | 635 | 250 | 615 | |
95/XL | H | 6J | 201 | 635 | 290 | 690 | ||
215/65R15 | 96 | H | 61/2J | 221 | 661 | 250 | 710 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
45 | 195/45R16 | 84/XL | V | 6 1/2J | 195 | 582 | 290 | 500 |
215/45R16 | 90/XL | V | 7J | 213 | 600 | 290 | 600 | |
55 | 195/55R16 | 91/XL | V | 6J | 201 | 620 | 290 | 615 |
205/55R16 | 91 | V | 61/2J | 214 | 632 | 250 | 615 | |
94/XL | V | 61/2J | 214 | 632 | 290 | 670 | ||
215/55R16 | 97/XL | V | 7J | 226 | 642 | 290 | 730 | |
60 | 205/60R16 | 96/XL | V | 6J | 209 | 652 | 290 | 710 |
70 | 215/70R16 | 100 | H | 61/2J | 221 | 708 | 250 | 800 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
45 | 205/45ZR17 | 88/XL | W | 7J | 206 | 616 | 290 | 560 |
215/45ZR17 | 91/XL | W | 7J | 213 | 626 | 290 | 615 | |
225/45ZR17 | 94/XL | W | 71/2J | 225 | 634 | 290 | 670 | |
235/45ZR17 | 97/XL | W | 8J | 236 | 644 | 290 | 730 | |
245/45ZR17 | 99/XL | W | 8J | 243 | 652 | 290 | 775 | |
50 | 205/50ZR17 | 93/XL | W | 61/2J | 214 | 638 | 290 | 650 |
215/50ZR17 | 95/XL | W | 7J | 226 | 648 | 290 | 690 | |
225/50ZR17 | 98/XL | W | 7J | 233 | 658 | 290 | 750 | |
55 | 215/55ZR17 | 98/XL | W | 7J | 226 | 668 | 290 | 750 |
225/55ZR17 | 101/XL | W | 7J | 233 | 680 | 290 | 825 | |
235/55ZR17 | 103/XL | W | 71/2J | 245 | 690 | 290 | 875 | |
60 | 215/60R17 | 100/XL | V | 61/2J | 221 | 690 | 290 | 800 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
40 | 225/40ZR18 | 92/XL | W | 8J | 230 | 637 | 290 | 630 |
45 | 225/45R18 | 95/XL | V | 71/2J | 225 | 659 | 290 | 690 |
55 | 215/55R18 | 99/XL | V | 7J | 226 | 693 | 290 | 775 |
