Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
70 | 175/70R13 | 82 | T | 5J | 177 | 576 | 250 | 475 |
80 | 155/80R13 | 83/XL | Q | 41/2J | 157 | 578 | 280 | 487 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
60 | 185/60R14 | 82 | T | 51/2J | 189 | 578 | 250 | 475 |
65 | 175/65R14 | 86/XL | T | 5J | 177 | 584 | 290 | 530 |
185/65R14 | 86 | T | 51/2J | 189 | 596 | 250 | 530 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
60 | 185/60R15 | 84 | T | 51/2J | 189 | 603 | 250 | 500 |
65 | 185/65R15 | 88 | H | 51/2J | 189 | 621 | 250 | 560 |
195/65R15 | 95/XL | T | 6J | 201 | 635 | 290 | 690 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
55 | 205/55R16 | 94/XL | T | 61/2J | 214 | 632 | 290 | 670 |
60 | 205/60R16 | 92 | H | 6J | 209 | 652 | 250 | 630 |
65 | 215/65R16 | 102/XL | H | 61/2J | 221 | 686 | 290 | 850 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
45 | 225/45R17 | 94/XL | H | 71/2J | 225 | 634 | 290 | 670 |
50 | 225/50R17 | 98/XL | H | 7J | 233 | 658 | 290 | 750 |
55 | 215/55R17 | 98/XL | H | 7J | 226 | 668 | 290 | 750 |
225/55R17 | 101/XL | H | 7J | 233 | 680 | 290 | 825 | |
60 | 215/60R17 | 96 | H | 61/2J | 221 | 690 | 250 | 710 |
225/60R17 | 103/XL | H | 61/2J | 228 | 702 | 290 | 875 | |
65 | 225/65R17 | 102 | T | 61/2J | 228 | 724 | 250 | 850 |
235/65R17 | 104 | T | 7J | 240 | 738 | 250 | 900 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
55 | 275/55R20 | 117/XL | H | 81/2J | 284 | 810 | 290 | 1285 |
